Malossi Moped racing exhaust mhr 3219492
Code: 3219492
The Moped Racing muffler is one of the essential components for the development of a vehicle and has been specifically designed to give the engine an increase in power at medium and high revs.
It has a profile that allows it to be mounted on ALL Ciao, Bravo, Si, Grillo mopeds and is sized to be coupled with ALL aluminum Racing cylinder kits currently on sale.
Created for the most extreme elaborations, it presents a decidedly captivating path with minimal losses and able to underline the sporting vocation of each vehicle.
The generous dimensions and lengths reveal the potential of this system at a glance.
The amazing results recorded on the test bench reveal a frightening increase in the torque curve and an improvement in maximum power never achieved with any other moped muffler!
Technical features:
-Muffler
Designed for assembly in all Ciao, Bravo, Si, Grillo mopeds in combination with Malossi aluminum thermal units. Made of special steel sheet (thickness 0.8mm), obtained with T.I.G. and M.I.G. and handcrafted oxy-acetylene welding. Transparent varnish.
- Union
Special for Malossi Moped cylinder kits: flange with ears for anchoring the support springs (it is no longer necessary to drill the cylinder fins to connect the springs), profile obtained with high precision laser cutting and connection with hole obtained with CNC machines with high precision for an optimal coupling with the exhaust duct.
-Nozzle
With passage section calibrated to achieve the maximum available back pressure.
-Silencer
In aluminum, anodized Nitro blue with terminal tube drowned in the bottom for a more attractive design.
-Connection to muffler
Made using silent blocks and spacers (when required) fixed directly to the frame, in an extremely solid and stable way. Since this is an extreme rig, some minimal modifications to the frame need to be made. A drilling for fixing the silentblocks. Assembly of the crankcase cover is not possible.
ATTENTION: it is necessary to remove the original pedals and the sprocket for the chain engagement.
Malossi exhaust for:
3219492 MALOSSI MOPED RACING MHR EXHAUST FOR PIAGGIO BRAVO 50 2T
3219492 MALOSSI MOPED RACING MHR EXHAUST FOR PIAGGIO BOSS 50 2T
3219492 MALOSSI MOPED RACING MHR EXHAUST FOR PIAGGIO BOXER 50 2T
3219492 MALOSSI MOPED RACING MHR EXHAUST FOR PIAGGIO CIAO 50 2T
3219492 MALOSSI MOPED RACING MHR EXHAUST FOR PIAGGIO CIAO PX 50 2T
3219492 MALOSSI MOPED RACING MHR EXHAUST FOR PIAGGIO GRILLO 50 2T
3219492 MALOSSI MOPED RACING MHR EXHAUST FOR PIAGGIO SI 50 2T
3219492 MALOSSI MOPED RACING MHR EXHAUST FOR PIAGGIO SUPERBRAVO 50
