Malossi internal rotor ignition for Mhr Team II
Malossi Code: 5519634
Malossi ignition for Mhr Team II
Malossi ignitions concentrate in themselves the maximum of technology applied to competitions. The new internal rotor ignitions arise from the need to overcome the technical limitations of the original flywheel-ignition groups, which above 10,000 rpm do not guarantee a constant performance, causing considerable and sometimes insurmountable tuning problems.
We have made the control unit even more immune to disturbances, developing a microprocessor based on uP STM8 - 8 Bit with higher computing capacity @ 20 MIPS to guarantee a much higher spark accuracy than the previous version!
The MHR Team II range is equipped with a non-remappable variable advance control unit with 3 trimmers:
-the first (MAPS) to determine the advance map selection
- the second (OFFSET) allows you to move the selected map + or - 2 °
- the third (LIM) indicated especially for 4-stroke engines, allows you to vary the intervention of the rev limiter (from 11,500 to 14,300 Rpm + limiter excluded)
It is also equipped with 8 preset mappings which are divided into:
-1 for 4T variable advance engines
-6 for 2T variable advance engines
-1 with fixed advance
Other key components have also been revised such as the high voltage coil, now capable of delivering a maximum discharge voltage> 40KV for normal engine speeds from> 3000RPM and an extraordinary rise time @ 10bar> 1750 V / uS.
One of the most important innovations is the new rotor-stator unit, whose static component has been completely redesigned from a mechanical and electronic point of view!
Malossi ignition compatible with:
5519634 INTERNAL ROTOR IGNITION MALOSSI PIAGGIO GILERA 2T AC AIR MHR TEAM II
5519634 INTERNAL ROTOR IGNITION MALOSSI APRILIA MOJITO CUSTOM 50 2T MHR TEAM II
5519634 INTERNAL ROTOR IGNITION MALOSSI APRILIA SCARABEO STREET 50 2T (PIAGGIO) MHR TEAM II
5519634 INTERNAL ROTOR IGNITION MALOSSI APRILIA SPORTCITY ONE STREET 50 2T euro 2 MHR TEAM II
5519634 INTERNAL ROTOR IGNITION MALOSSI APRILIA SR MOTARD 50 2T euro 2 MHR TEAM II
5519634 INTERNAL ROTOR IGNITION MALOSSI DERBI ATLANTIS - BULLET 50 2T 2003-> MHR TEAM II
5519634 INTERNAL ROTOR IGNITION MALOSSI DERBI VARIANT Sport 50 2T MHR TEAM II
5519634 INTERNAL ROTOR IGNITION MALOSSI GILERA EASY MOVING 50 2T MHR TEAM II
5519634 INTERNAL ROTOR IGNITION MALOSSI GILERA ICE 50 2T MHR TEAM II
5519634 INTERNAL ROTOR IGNITION MALOSSI GILERA STORM 50 2T MHR TEAM II
5519634 INTERNAL ROTOR IGNITION MALOSSI GILERA STALKER 50 2T MHR TEAM II
5519634 INTERNAL ROTOR IGNITION MALOSSI GILERA TYPHOON 50 2T MHR TEAM II
5519634 INTERNAL ROTOR IGNITION MALOSSI GILERA TYPHOON X 50 2T MHR TEAM II
5519634 INTERNAL ROTOR IGNITION MALOSSI ITALJET JET SET 50 2T MHR TEAM II
5519634 INTERNAL ROTOR IGNITION MALOSSI PIAGGIO DIESIS 50 2T MHR TEAM II
5519634 INTERNAL ROTOR IGNITION MALOSSI PIAGGIO NRG EXTREME 50 2T MHR TEAM II
5519634 INTERNAL ROTOR IGNITION MALOSSI PIAGGIO FLY 50 2T MHR TEAM II
5519634 INTERNAL ROTOR IGNITION MALOSSI PIAGGIO FREE 50 2T MHR TEAM II
5519634 INTERNAL ROTOR IGNITION MALOSSI PIAGGIO LIBERTY 50 2T MHR TEAM II
5519634 INTERNAL ROTOR IGNITION MALOSSI PIAGGIO NRG MC3 DT 50 2T MHR TEAM II
5519634 INTERNAL ROTOR IGNITION MALOSSI PIAGGIO NRG Power DT 50 2T (C453M) MHR TEAM II
5519634 INTERNAL ROTOR IGNITION MALOSSI PIAGGIO SFERA RESTYLING 50 2T MHR TEAM II
5519634 INTERNAL ROTOR IGNITION MALOSSI PIAGGIO TYPHOON 50 2T 2007-> 2010 MHR TEAM II
5519634 INTERNAL ROTOR IGNITION MALOSSI PIAGGIO ZIP Fast Rider 50 2T MHR TEAM II
5519634 INTERNAL ROTOR IGNITION MALOSSI PIAGGIO ZIP 50 2T 2000-> MHR TEAM II
5519634 INTERNAL ROTOR IGNITION MALOSSI PIAGGIO ZIP 50 2T <-1999 MHR TEAM II
5519634 INTERNAL ROTOR IGNITION MALOSSI VESPA ET2 50 2T 2000-> MHR TEAM II
5519634 INTERNAL ROTOR IGNITION MALOSSI VESPA ET2 50 2T <-1999 MHR TEAM II
5519634 IGNITION INTERNAL ROTOR MALOSSI VESPA LX 50 2T MHR TEAM II
5519634 INTERNAL ROTOR IGNITION MALOSSI VESPA Primavera 50 2T euro 2 (C533M) MHR TEAM II
5519634 INTERNAL ROTOR IGNITION MALOSSI VESPA S 50 2T euro 2 (C381M) MHR TEAM II
5519634 IGNITION INTERNAL ROTOR MALOSSI VESPA Sprint 50 2T euro 2 MHR TEAM II
