Carburetor sha 14/14 L Dellorto code 2183, suitable for motorcycles and minimoto. Dimensions and characteristics of the carburettor sha 14 14 l inlet for manifold 19 mm, filter connection 59 mm, fuel pipe connection 5.5 mm, manual lever air, standard main jet m5 size 68. This carburetor is commonly fitted as standard on minimoto and small displacement scooters.
Dellorto Code: 02183
Carburetor sha 14 14 L Dellorto code 2183, suitable for motorcycles and minimoto. Dimensions and characteristics of the carburettor sha 14 14 l inlet for manifold 19 mm, filter connection 59 mm, fuel pipe connection 5.5 mm, manual lever air, standard main jet m5 size 68. This carburetor is commonly fitted as standard on minimoto and small displacement scooters.
Dellorto Code: 02183
Reference: 1486 x 02
Brand: DELLORTO
Dellorto maximum jet M5 for Phbg Sha and others carburetors. Size available from 30 to 140.
Reference: FB 001
Brand: OMG
Omg petrol filter made in Italy, with 6 mm hose connection.
Reference: 143.465.001
Brand: POLINI
Air filter for Polini minimoto, the filter is compatible with the SHA 14 carburettor. Polini code: 143.465.001
Reference: 143.465.005
Brand: POLINI
Sha 14 14 L carburetor flange, for 34 mm diameter air filter attachment. Polini Code 143.465.005
Reference: 2508
Brand: DELLORTO
Original Dellorto PHBG 15 BS carburetor with quick-access cap for needle and slide. Optimized performance.
Reference: 201.0168
Brand: POLINI
Polini carburettor diameter 28. Polini code: 201.0168 Air filter connection d.48.8 Carburetor sleeve d.34.8
Reference: 201.1501
Brand: POLINI
Polini carburettor 15 Cp wire air starter Maximum jet 70 Minimum Jet 36 Needle 14/22 24x30 valve Pulverizer bush d.2,6 Polini Code: 201.1501
Reference: 09853
Brand: DELLORTO
Dellorto PHDG 19 Carburetor. Code: 09853. The Dellorto PHBD 19 carburetor, designed for high-performance two-stroke engines, offers excellent power delivery, rapid response, and maximum reliability, ideal for sports and racing tuning.
Reference: 201.1904
Brand: POLINI
Polini Cp 19 diameter carburettor with clamp, knob air choke. Maximum jet 66 Minimum jet 42 Needle 14/22 24x30 valve Pulverizer bush d.2,6 Manifold connection diameter 24 mm Polini Code: 201.1904
Reference: 201.2102
Brand: POLINI
Polini 21 Cp carburetor, clamp attachment, knob air starter. Polini 21 carburetor settings: Maximum jet 72 Minimum jet 42 Needle 14/22 24x30 valve Pulverizer bush d.2,7 Polini Code: 201.2102
Reference: 02631
Brand: DELLORTO
Dellorto Phbg 19 ds carburettor Diffuser: 19mm Motor connection: ELASTIC (MALE) ø25 Filter connection: M32 x 1.25mm Air start: MANUAL AIR (CABLE) Compatible with engines: 2 STROKE Connection for mixer Gas valve: 30 Conical needle: W9 Pulverizer: 262 AN Maximum jet: 75 by 5mm Minimum jet: 45 Starter jet: 60 Float: 4 grams
Reference: 02873-Ohvale
Brand: DELLORTO
Dellorto carburetor for Ohvale 110cc 4-stroke. Dellorto PHBL 24 BS carburetor for Ohvale. The collaboration between Dellorto and Ohvale extends across the entire product range, starting with the OHVALE GP-0 110 4S, which will be equipped with the DELLORTO PHBL 24 BS carburetor. All are specifically calibrated and tested on DELL'ORTO test benches.
Reference: 01438
Brand: DELLORTO
Dellorto PHVA 17.5 US 01438 carburettor. Dellorto code: 01438. 17.5 dellorto carburetor phva 17.5 us version for scooters. Motor connection: flange. Filter connection: 35 mm. Air starting device: Automatic starter predisposition. For engines: 2 stroke. Mixer: yes. Gas valve: 15362.40. Conical pin: 16250.27. Pulverizer: 15192.209 Gn. Maximum jet: 613.90....
Reference: 02686
Brand: DELLORTO
Dellorto phbg 19 bs 02686 carburettor. Dellorto code: 02686. Dellorto 19 carburetor phbg 19 bs version for scooters and motorbikes. Motor connection: 25 mm male elastic. FILTER CONNECTION: M32 x 1.25mm. Air starting device: manual air (wire). For engines: 2t. Recommended for scooters and motorcycles. Mixer: NO. Gas valve: 40 - 947540. Conical pin: W7 -...
Reference: 201.2402
Brand: POLINI
Polini Cp 24 carburetor for Vespa 125 Primavera ET3 with filter. Polini Code: 201.2402 The Polini 24 carburettor is mounted on manifolds with a 28.5 mm diameter rubber sleeve. Polini 24 CP carburettor data sheet: Maximum jet 104 Minimum Jet 36 Needle 14/22 25x30 valve Pulverizer bush d.2,7
Reference: 03500-Ohvale
Brand: DELLORTO
Dellorto carburetor for Ohvale 190cc 4-stroke. Dellorto PHBH 28 BD carburetor for Ohvale. Code: 03500 28 carburetor specifically for Ohvale 190cc. The collaboration between Dellorto and Ohvale extends to the entire OHVALE product range. The GP-0 160 and OHVALE GP-2 190 now feature the DELLORTO PHBH 28 BD carburetor, all with dedicated calibration and...
Reference: 00592
Brand: DELLORTO
Dellorto SI 24.24 E carburetor with mixer 00592. Dell'Orto / Spaco SI 24.24 E carburetor with mixer, Ø 24 mm, 116 main jet. Compatible with Vespa PX200, Rally 200, PX125, PX150, and other Largeframe models.
Reference: 201.0175
Brand: POLINI
Polini SI 26/26E carburetor with oil mixer and R617 calibration for Vespa PX and Cosa 2T models. Plug & play replacement. Code 201.0175.
Reference: 03309
Brand: DELLORTO
Dellorto PHBH 26 AS Carburetor Dellorto Part Number: 03309 Manufacturer: DELLORTO
Reference: 01821-00
Brand: DELLORTO
Dellorto carburettor for Piaggio Ciao sha 12-10. Dellorto Code: 01821-00 (Original Piaggio Ciao carburetor).
