Carburetor Dellorto phbg 15 bs
  • Carburetor Dellorto phbg 15 bs
  • Carburetor Dellorto phbg 15 bs
  • Carburetor Dellorto phbg 15 bs

Carburetor Dellorto phbg 15 bs

2508

Original Dellorto PHBG 15 BS carburetor with quick-access cap for needle and slide. Optimized performance.

€129.36
€71.15 Save 45%
Tax included
Quantity
In Stock

Description

The Dellorto PHBG 15 BS carburetor part number 02508 is a genuine Dellorto carburetor, designed to deliver reliability and optimized performance.

This latest version features a quick-access cap, allowing fast access to the needle and throttle slide, making tuning and maintenance easier.

The PHBG 15 BS is a versatile and precise carburetor, ideal for those looking for performance, ease of adjustment and adaptability to different setups.

Technical specifications:

  • Engine connection: 25 mm
  • Air filter connection: 32 mm
  • Air system: direct
  • Venturi: 15 mm
  • Throttle valve: 40
  • Needle: 9595.23
  • Atomizer: 266 AN
  • Main jet: 90
  • Idle jet: 60
  • Float: 4 g

Main features:

  • Genuine Dellorto carburetor
  • Product code: 02508
  • Model: PHBG 15 BS
  • Quick-access cap
  • Easy tuning and maintenance
  • Optimized performance
Product Details
2508

Data sheet

Application
Universal
Compatible with
Universale
Engine type
2 stroke
Carburetor size
15
