Malossi Rs24 rear shock absorber 4614223
Malossi code: 4614223
Malossi rear Rs24 shock absorber, 330 mm wheelbase for 10" wheel.
The versatility of this suspension has proven surprising thanks to the 3 new adjustment systems, which enhance its use on the road and track:
-adjustment of the hydraulic system in extension to absorb all the roughness of the terrain;
-spring preload to adapt the vehicle's running position;
- setup variation system for cornering behaviour.
Technical features
-These special shock absorbers have technical characteristics that represent the maximum technological expression available on the market today.
-Oleopneumatic suspension with pressurized nitrogen chambers
-Separate compensation tank which allows an increase in the quantity of internal fluids
-Hydraulic adjustment in rebound and compression via ring nut
- Wheelbase adjustment
- Vehicle trim adjustment
-Stroke: art.4614223: 70 mm – art.4614245: 40 mm
- Wheelbase: art.4614223: 330 mm – art.4614245: 270 mm
-Adjustable attachment forged in ergal 55 with anodic oxidation
-Attachment made from Ergal 55 with anodic oxidation.
NOTE: the art. 4614223 is equipped with all the necessary nuts and bolts for application on both Minarelli and Piaggio engines.
