Malossi Tc unit Rpm control K15 5512791 electronic control unit including coil
Malossi code: 5512791
Malossi Tc unit Rpm control K15 electronic control unit including coil
The Malossi control units also allow the rev limiter present on the standard control units to be eliminated: in this way the power and torque of the engine can be fully exploited even at the highest speeds up to 20,000 rpm. The Malossi control units have capacitive discharge and therefore allow the emission of disturbances during the voltage discharge to be limited to a minimum; they deliver an almost perfect voltage peak on the spark plug (35,000 - 50,000 volts based on the engine speed) and give very high discharge voltages and discharge currents with surprising consistency as the number of engine revolutions varies.
TC UNIT R.P.M. CONTROL
On these control units there is a microswitch, which can be positioned as desired on your vehicle in a sheltered place, which activates the rev limiter of your engine. The number of revolutions at which the rev limiter intervenes is adjustable depending on the type of your engine. To adjust the speed at which it intervenes, referring to the odometer of your vehicle, and acting on the micropotentiometer on the control unit it is possible to adapt the intervention point of the limiter. The adjustment potentiometer has considerable sensitivity, so it is necessary to make very small rotations during the adjustment phase until reaching the insertion point of the limiter suitable for your scooter.
Technical data
- Control unit power supply: original
-Maximum number of revolutions/minute: 20,000
-Discharge voltage: 35,000 - 50,000 volts
-Advance: fixed
-Limiter: present, adjustable and excludable
Malossi control unit for:
Malossi control unit for APRILIA MX 50 2T LC (MINARELLI AM 6) ONLY FOR vehicles with DUCATI FLYWHEEL and WITHOUT IMMOBILIZER KEY.
Malossi control unit for APRILIA RS 50 2T LC (MINARELLI AM 3 > 6) ONLY FOR vehicles with DUCATI FLYWHEEL and WITHOUT IMMOBILIZER KEY.
Malossi control unit for APRILIA RS 50 2T LC euro 2 2006-> (DERBI D50B1) ONLY FOR vehicles with DUCATI FLYWHEEL and WITHOUT IMMOBILIZER KEY.
Malossi control unit for APRILIA TUONO 50 2T LC (MINARELLI AM 6) ONLY FOR vehicles with DUCATI FLYWHEEL and WITHOUT IMMOBILIZER KEY.
Malossi control unit for BETA RR ENDURO 50 2T LC (MINARELLI AM 6) ONLY FOR vehicles with DUCATI FLYWHEEL and WITHOUT IMMOBILIZER KEY.
Malossi control unit for BETA RR SUPERMOTARD 50 2T LC (MINARELLI AM 6) ONLY FOR vehicles with DUCATI FLYWHEEL and WITHOUT IMMOBILIZER KEY.
Malossi control unit for BETA RR SUPERMOTARD ALU 50 2T LC (MINARELLI AM 6) ONLY FOR vehicles with DUCATI FLYWHEEL and WITHOUT IMMOBILIZER KEY.
Malossi control unit for DERBI GPR NUDE 50 2T LC <-2005 (EBS050) ONLY FOR vehicles with DUCATI FLYWHEEL and WITHOUT IMMOBILIZER KEY.
Malossi control unit for DERBI GPR NUDE 50 2T LC 2006-> (D50B0) ONLY FOR vehicles with DUCATI FLYWHEEL and WITHOUT IMMOBILIZER KEY.
Malossi control unit for DERBI GPR RACING 50 2T LC 2004->2005 (EBS050) ONLY FOR vehicles with DUCATI FLYWHEEL and WITHOUT IMMOBILIZER KEY.
Malossi control unit for DERBI GPR RACING 50 2T LC 2006-> (D50B0) ONLY FOR vehicles with DUCATI FLYWHEEL and WITHOUT IMMOBILIZER KEY.
Malossi control unit for DERBI GPR R 50 2T LC euro 2 2012-> ONLY FOR vehicles with DUCATI FLYWHEEL and WITHOUT IMMOBILIZER KEY.
Malossi control unit for FANTIC CABALLERO 50 2T LC euro 4 2019-> (MINARELLI AM 6) ONLY FOR vehicles with DUCATI FLYWHEEL and WITHOUT IMMOBILIZER KEY.
Malossi control unit for HM CR E DERAPAGE 50 2T LC (MINARELLI AM 6) ONLY FOR vehicles with DUCATI FLYWHEEL and WITHOUT IMMOBILIZER KEY.
Malossi control unit for HM CRE SIX Comp. 50 2T LC 2013-> (MINARELLI AM 6) ONLY FOR vehicles with DUCATI FLYWHEEL and WITHOUT IMMOBILIZER KEY.
Malossi control unit for HM DERAPAGE RR 11 50 2T LC (MINARELLI AM 6) ONLY FOR vehicles with DUCATI FLYWHEEL and WITHOUT IMMOBILIZER KEY.
Malossi control unit for HUSQVARNA CH RACING 50 2T LC (MINARELLI AM 6) ONLY FOR vehicles with DUCATI FLYWHEEL and WITHOUT IMMOBILIZER KEY.
Malossi control unit for MALAGUTI XSM - XTM 50 2T LC (MINARELLI AM 6) ONLY FOR vehicles with DUCATI FLYWHEEL and WITHOUT IMMOBILIZER KEY.
Malossi control unit for MBK X-LIMIT 50 2T LC (MINARELLI AM 6) ONLY FOR vehicles with DUCATI FLYWHEEL and WITHOUT IMMOBILIZER KEY.
Malossi control unit for MBK
Malossi control unit for PEUGEOT XPS 50 2T LC (MINARELLI AM 6) ONLY FOR vehicles with DUCATI FLYWHEEL and WITHOUT IMMOBILIZER KEY.
Malossi control unit for PEUGEOT
Malossi control unit for RIEJU RS2 50 2T LC (MINARELLI AM 6) ONLY FOR vehicles with DUCATI FLYWHEEL and WITHOUT IMMOBILIZER KEY.
Malossi control unit for SHERCO HRD 50 2T LC (MINARELLI AM 6) ONLY FOR vehicles with DUCATI FLYWHEEL and WITHOUT IMMOBILIZER KEY.
Malossi control unit for YAMAHA DT 50 R 50 2T LC euro 2 (MINARELLI AM 6) For Vehicles PRODUCED <-2006 (see in the REGISTRATION MANUAL) - ONLY FOR vehicles with DUCATI FLYWHEEL and WITHOUT IMMOBILIZER KEY.
Malossi control unit for YAMAHA DT 50
Malossi ECU for YAMAHA TZR 50 2T LC (MINARELLI AM 6) For Vehicles PRODUCED <-2006 (see in the REGISTRATION MANUAL) - ONLY FOR vehicles with DUCATI FLYWHEEL and WITHOUT IMMOBILIZER KEY.
