Malossi Mhr Team crankshaft 5317822
Malossi code: 5317822
Malossi Mhr Team crankshaft with 13 mm diameter pin, 90 mm connecting rod, 44 mm stroke 5317822.
IMPROVEMENTS SINCE THE PREVIOUS VERSION:
10% more inertial mass.
Reinforced connecting rod to withstand higher loads.
Sprocket-side crankshaft increased driveshaft cross-sectional area by 10% resulting in increased strength.
Increased oil seal, drive side, from shaft diameter 19mm to 20mm, increasing shaft strength.
TECHNICAL FEATURES:
Half shaft material: 18 Ni Cr Mo5.
Half shafts and forged monolithic rotating masses.
Machining on high precision machine tools.
Five heat treatments on all components.
High surface finish to improve reliability.
Dynamic balancing up to 16,000 rpm.
Forged connecting rod in 18 Ni Cr Mo5 copper plated, coupled to shaft with high speed precision roller bearing.
N.B.: INTERVENTIONS ON THE CRANKCASE, BORING.
ONLY COMBINE WITH thermal units 3115385 - 3115883 (3113042/.T0 AFTER FITTING SPACER 0716345).
Malossi crankshaft for:
Malossi crankshaft for Aprilia sr (carb.) 50 2t lc 2004-> (piaggio).
Malossi crankshaft for Aprilia sr r (carb.) 50 2t lc (piaggio).
Malossi crankshaft for Aprilia sr r 50 2t lc euro 4 2018-> (piaggio ca81m).
Malossi crankshaft for Aprilia sr street 50 2t lc euro 2.
Malossi crankshaft for Derbi gp1 50 2t lc.
Malossi crankshaft for Derbi gp1 open 50 2t lc.
Malossi crankshaft for Derbi gp1 revolution 50 2t lc.
Malossi crankshaft for Gilera dna 50 2t lc.
Malossi crankshaft for Gilera runner 50 2t lc.
Malossi crankshaft for Gilera runner sp 50 2t lc <-2005.
Malossi crankshaft for Gilera runner sp 50 2t lc 2006-> (c451m).
Malossi crankshaft for Piaggio nrg 50 2t lc.
Malossi crankshaft for Piaggio nrg extreme 50 2t lc.
Malossi crankshaft for Piaggio nrg mc2 50 2t lc <-1997.
Malossi crankshaft for Piaggio nrg mc2 50 2t lc 1998->.
Malossi crankshaft for Piaggio nrg mc3 dd 50 2t lc.
Malossi crankshaft for Piaggio nrg power 50 2t lc euro 4 2018->2020 (ca71m).
Malossi crankshaft for Piaggio nrg power dd 50 2t lc.
Malossi crankshaft for Piaggio ntt 50 2t lc.
Malossi crankshaft for Piaggio quartz 50 2t lc.
Malossi crankshaft for Piaggio zip sp 50 2t lc <-2000.
Malossi crankshaft for Piaggio zip sp 50 2t lc 2001->.
