Malossi Tc Unit K15 5513195 electronic control unit
Code: 5513195
Malossi Tc Unit K15 electronic control unit complete with coil
The incessant development of electronics in the motor sector has led Malossi to the creation and marketing of a complete line of electronic control units for road and racing scooters which embody maximum technology.
Each control unit model has been expressly studied for the scooter on which it will be mounted, for this reason after countless tests on static and roller benches and on race circuits an optimal ignition mapping (fixed or variable) has been defined in order to obtain the maximum performance from the vehicle. The Malossi electronic control units have also been designed to allow extremely simple installation, as they are interchangeable with the standard control units; compact and ergonomic, they connect perfectly to the original connectors.
The Malossi ECUs also allow you to eliminate the rev limiter present on the stock ECUs: in this way you can fully exploit the power and torque of the engine even at the highest revs up to 20,000 rpm. The Malossi control units are capacitive discharge and therefore allow to limit the emission of disturbances as much as possible during the voltage discharge; they deliver an almost perfect voltage peak on the spark plug (35,000 - 50,000 volts based on the engine speed) and give very high discharge voltages and discharge currents with surprising constancy as the engine rpm varies.
Technical data
ECU power supply: original
Maximum rpm: 20,000
Discharge voltage: 35,000 - 50,000 volts
Advance: fixed
Malossi ECU for:
5513195 TC UNIT MALOSSI K15 ELECTRONIC CONTROL UNIT + PIAGGIO COIL
5513195 ECU MALOSSI TC UNIT K15 APRILIA SR (CARB.) 50 2T LC 2004 onwards (PIAGGIO) COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 APRILIA SR R (CARB.) 50 2T LC (PIAGGIO) COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 APRILIA SR STREET 50 2T LC EURO 2 COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 APRILIA SR MOTARD 50 2T EURO 2 COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 APRILIA SCARABEO STREET 50 2T (PIAGGIO) COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 APRILIA SPORTCITY ONE STREET 50 2T EURO 2 COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 APRILIA MOJITO CUSTOM 50 2T COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 DERBI GP1 50 2T LC COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 DERBI GP1 OPEN 50 2T LC COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 DERBI GP1 REVOLUTION 50 2T LC COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 DERBI VARIANT SPORT 50 2T COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 GILERA RUNNER 50 2T LC COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 GILERA RUNNER SP 50 2T LC up to 2005 COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 GILERA RUNNER SP 50 2T LC 2006 onwards (C451M) COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 GILERA DNA 50 2T LC COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 GILERA STALKER 50 2T COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 GILERA TYPHOON X 50 2T COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 GILERA TYPHOON 50 2T COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 GILERA ICE 50 2T COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 GILERA STORM 50 2T COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 GILERA EASY MOVING 50 2T COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 ITALJET JET SET 50 2T COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 ITALJET TORPEDO NEW 50 2T COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 PIAGGIO NRG 50 2T LC COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 PIAGGIO NRG EXTREME 50 2T LC COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 PIAGGIO NRG MC2 50 2T LC up to 1997 COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 PIAGGIO NRG MC2 50 2T LC 1998 onwards COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 PIAGGIO NRG MC3 DD 50 2T LC COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 PIAGGIO NRG POWER DD 50 2T LC COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 PIAGGIO NTT 50 2T LC COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 PIAGGIO QUARTZ 50 2T LC COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 PIAGGIO ZIP SP 50 2T LC up to 2000 COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 PIAGGIO ZIP SP 50 2T LC 2001 onwards COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 PIAGGIO FREE 50 2T COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 PIAGGIO NRG MC3 DT 50 2T COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 PIAGGIO TYPHOON 50 2T 2007 to 2010 COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 PIAGGIO NRG EXTREME 50 2T COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 PIAGGIO ZIP 50 2T 2000 onwards COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 PIAGGIO ZIP FAST RIDER 50 2T COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 PIAGGIO SFERA RESTYLING 50 2T COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 PIAGGIO NRG POWER DT 50 2T (C453M) COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 PIAGGIO LIBERTY 50 2T COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 PIAGGIO TYPHOON 50 2T EURO 2 2011 to 2017 (C421M) COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 PIAGGIO FLY 50 2T COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 PIAGGIO DIESIS 50 2T COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 PIAGGIO ZIP 50 2T up to 1999 COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 PIAGGIO SFERA 50 2T COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 PIAGGIO SFERA 75 2T COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 VESPA ET2 50 2T up to 1999 COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 VESPA ET2 50 2T 2000 onwards COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 VESPA S 50 2T EURO 2 (C381M) COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 VESPA SPRINT 50 2T EURO 2 COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 VESPA PRIMAVERA 50 2T EURO 2 (C533M) COMPLETE WITH COIL
5513195 ECU MALOSSI TC UNIT K15 VESPA LX 50 2T COMPLETE WITH COIL
