Xmotorstore Payments
Malossi cylinder for T Max 530 cc diameter 70 mm in aluminum 3115423
Code: 3115423
Malossi cylinder diameter 70 mm in aluminum h2o for Yamaha T Max 530 cc
Technical features
-Bore: Ø 70 mm
- Stroke: 73 mm
- Total displacement: 560 cc.
- Compression ratio: 1:12
-Maximum power at: 7,800 rpm.
- Split monolithic cylinder: in special alloy of aluminum-silicon-copper, tempered and stabilized.
- Rods: with Cermetal (ni-ca-sil) coating worked with extreme precision on the latest generation machining centers.
- Cross sanding at 110 / 130. °
-Forged pistons Ø 70 pin 16 with 3 segments: in special aluminum alloy (copper-silicon), tempered and tinned, shaped top with valve imprint, racing design, reinforced and lightened, at constant thickness.
Segments no. 3:
-1 ° compression in chromed steel,
-2 ° oil scraper in phosphated steel,
-3 ° decomposed in chromed steel with spring.
-Increase in power of more than 15%.
- Extreme reliability.
- Made in Italy technology.
- Entirely designed and manufactured in the Calderara di Reno factories.
Personally cared for at every stage, from design to production, by Malossi technicians, like all products bearing this brand.
The two-barrel monobloc with a dry and clean design created by Yamaha has been customized by Malossi with significant changes and updates that have made it possible to significantly increase the bore, without compromising the original mechanical and thermal balance.
The design of the pistons, forged in a special alloy, and designed to withstand the stress of use over long distances, is quite particular.
Nothing has been left to chance, from the seals to the biconical pin in super-alloyed steel and the elastic band in chromed and nitrided steel.
Every detail is a precious contribution to making this thermal unit truly exclusive.
Malossi cylinder compatible with:
3115423 KIT BI-CYLINDER MALOSSI 4T D. 70 alum. H2O YAMAHA T MAX 530 ie 4T LC 2012 (J409E)
3115423 CYLINDER KIT MALOSSI 560CC D.70 YAMAHA T MAX 530 IE 4T LC 2012-> 2014 (J409E) ALUMINUM H2O
3115423 CYLINDER KIT MALOSSI 560CC D.70 YAMAHA T MAX 530 IE 4T LC 2015-> 2016 (J409E) ALUMINUM H2O
3115423 CYLINDER KIT MALOSSI 560CC D.70 YAMAHA T MAX 530 IE 4T LC EURO 4 2017-> (J415E) ALUMINUM H2O
3115423 CYLINDER KIT MALOSSI 560CC D.70 YAMAHA T MAX DX 530 IE 4T LC EURO 4 2017-> (J415E) ALUMINUM H2O
3115423 CYLINDER KIT MALOSSI 560CC D.70 YAMAHA T MAX SX 530 IE 4T LC EURO 4 2017-> (J415E) ALUMINUM H2O
3115423 CYLINDER MALOSSI 560CC D.70 YAMAHA T MAX 530 IE 4T LC 2012-> 2014 (J409E) ALUMINUM H2O
3115423 CYLINDER MALOSSI 560CC D.70 YAMAHA T MAX 530 IE 4T LC 2015-> 2016 (J409E) ALUMINUM H2O
3115423 CYLINDER MALOSSI 560CC D.70 YAMAHA T MAX 530 IE 4T LC EURO 4 2017-> (J415E) ALUMINUM H2O
3115423 CYLINDER MALOSSI 560CC D.70 YAMAHA T MAX DX 530 IE 4T LC EURO 4 2017-> (J415E) ALUMINUM H2O
3115423 CYLINDER MALOSSI 560CC D.70 YAMAHA T MAX SX 530 IE 4T LC EURO 4 2017-> (J415E) ALUMINUM H2O
3115423 CYLINDER KIT MALOSSI 560CC D.70 YAMAHA TMAX 530 IE 4T LC 2012-> 2014 (J409E) ALUMINUM H2O
3115423 CYLINDER KIT MALOSSI 560CC D.70 YAMAHA TMAX 530 IE 4T LC 2015-> 2016 (J409E) ALUMINUM H2O
3115423 CYLINDER KIT MALOSSI 560CC D.70 YAMAHA TMAX 530 IE 4T LC EURO 4 2017-> (J415E) ALUMINUM H2O
3115423 CYLINDER KIT MALOSSI 560CC D.70 YAMAHA TMAX DX 530 IE 4T LC EURO 4 2017-> (J415E) ALUMINUM H2O
3115423 CYLINDER KIT MALOSSI 560CC D.70 YAMAHA TMAX SX 530 IE 4T LC EURO 4 2017-> (J415E) ALUMINUM H2O
3115423 CYLINDER MALOSSI 560CC D.70 YAMAHA TMAX 530 IE 4T LC 2012-> 2014 (J409E) ALUMINUM H2O
3115423 CYLINDER MALOSSI 560CC D.70 YAMAHA TMAX 530 IE 4T LC 2015-> 2016 (J409E) ALUMINUM H2O
3115423 CYLINDER MALOSSI 560CC D.70 YAMAHA TMAX 530 IE 4T LC EURO 4 2017-> (J415E) ALUMINUM H2O
3115423 CYLINDER MALOSSI 560CC D.70 YAMAHA TMAX DX 530 IE 4T LC EURO 4 2017-> (J415E) ALUMINUM H2O
3115423 CYLINDER MALOSSI 560CC D.70 YAMAHA TMAX SX 530 IE 4T LC EURO 4 2017-> (J415E) ALUMINUM H2O
