Malossi cylinder diameter 49 mm in aluminum with pin diameter 13 mm 4-stroke 3117771
Code: 3117771
4 Stroke cylinder
Material: primary aluminum alloy with a high content of tempered silicon, barrel with silicon carbide coating in a galvanic nickel matrix and cross-honed with two diamond passes with very tight tolerances.
Processing: on high precision numerically controlled machine tools.
Cylinder-piston couplings in selection of 0.05 mm.
Recalculated and increased heat exchange surfaces.
Piston
Super compact with three segments.
Material: special primary low thermal expansion silicon aluminum alloy with tin coating on the sliding walls.
Machining on numerical control machines.
Lightened and reinforced.
Enlarged heat exchange surfaces.
Segments
Special with high sliding and very high mechanical resistance.
1st compression segment in nitrided and chromed steel.
II ° segment in special cast iron.
Three-piece oil scraper in special alloy and chromed steel.
To be mounted EXCLUSIVELY with the INJTRONIC control unit art. 5517477B
PIAGGIO LIBERTY iGet 50 ie 4T euro 3 2016-> 2017 (C541M)
To be mounted EXCLUSIVELY with the INJTRONIC control unit art. 5518409
-PIAGGIO LIBERTY iGet 50 ie 4T euro 4 2018->
-PIAGGIO ZIP 3V I-GET 50 ie 4T euro 4 2018->
-VESPA PRIMAVERA 3V IGet 50 ie 4T euro 4 2018-> (CA03M)
-VESPA SPRINT 3V IGet 50 ie 4T euro 4 2018-> (CA01M)
To be mounted EXCLUSIVELY with the INJTRONIC control unit art. 5519266B
-PIAGGIO LIBERTY 3V iGet 50 ie 4T euro 5 2021->
-PIAGGIO ZIP S 3V iGet 50 ie 4T euro 5 2021->
-VESPA ZIP 3V iGet 50 ie 4T euro 5 2021->
-VESPA Primavera 3V iGet 50 ie 4T euro 5 2021-> (CD01M)
-VESPA SPRINT 3V IGet 50 ie 4T euro 5 2021-> (CD01M)
Malossi cylinder compatible with:
3117771 CYLINDER MALOSSI D.49 APRILIA SCARABEO 50 4T (PIAGGIO C373M) For ORIGINAL HEAD
3117771 CYLINDER MALOSSI D.49 APRILIA SCARABEO 4V 50 4T euro 2 For ORIGINAL HEAD
3117771 CYLINDER MALOSSI D.49 APRILIA SPORTCITY ONE 50 4T (PIAGGIO C377M) For ORIGINAL HEAD
3117771 CYLINDER MALOSSI D.49 ITALJET TORPEDO 50 4T For ORIGINAL HEAD
3117771 CYLINDER MALOSSI D.49 MALAGUTI CENTRO 50 4T euro 2 (C432M) For ORIGINAL HEAD
3117771 CYLINDER MALOSSI D.49 MALAGUTI CIAK MASTER 50 4T euro 2 For ORIGINAL HEAD
3117771 CYLINDER MALOSSI D.49 PIAGGIO FLY 50 4T For ORIGINAL HEAD
3117771 CYLINDER MALOSSI D.49 PIAGGIO NEW FLY 4V 50 4T euro 2 For ORIGINAL HEAD
3117771 CYLINDER MALOSSI D.49 PIAGGIO LIBERTY iGet 50 ie 4T euro 3 2016-> 2017 (C541M) ATTENTION: To be installed EXCLUSIVELY with the INJTRONIC control unit art. 5517477B
3117771 CYLINDER MALOSSI D.49 PIAGGIO LIBERTY iGet 50 ie 4T euro 4 2018-> 2020 (CA11M) ATTENTION: To be installed EXCLUSIVELY with the INJTRONIC control unit art. 5518409
3117771 CYLINDER MALOSSI D.49 PIAGGIO LIBERTY 3V iGet 50 ie 4T euro 5 2021-> ATTENTION: To be mounted EXCLUSIVELY with the INJTRONIC control unit art. 5519266B
3117771 CYLINDER MALOSSI D.49 PIAGGIO LIBERTY 50 4T For ORIGINAL HEAD
3117771 CYLINDER MALOSSI D.49 PIAGGIO LIBERTY 4V 50 4T euro 2 For ORIGINAL HEAD
3117771 CYLINDER MALOSSI D.49 PIAGGIO ZIP S 3V iGet 50 ie 4T euro 5 2021-> ATTENTION: To be installed EXCLUSIVELY with the INJTRONIC control unit art. 5519266B
3117771 CYLINDER MALOSSI D.49 PIAGGIO ZIP 3V iGet 50 ie 4T euro 4 2018-> 2020 ATTENTION: To be mounted EXCLUSIVELY with the INJTRONIC control unit art. 5518409
3117771 CYLINDER MALOSSI D.49 PIAGGIO ZIP 3V iGet 50 ie 4T euro 5 2021-> ATTENTION: To be mounted EXCLUSIVELY with the INJTRONIC control unit art. 5519266B
3117771 CYLINDER MALOSSI D.49 PIAGGIO ZIP 50 4T For ORIGINAL HEAD
3117771 CYLINDER MALOSSI D.49 VESPA ET4 50 4T For ORIGINAL HEAD
3117771 CYLINDER MALOSSI D.49 VESPA LX 50 4T For ORIGINAL HEAD
3117771 CYLINDER MALOSSI D.49 VESPA LX 4V 50 4T euro 2 For ORIGINAL HEAD
3117771 CYLINDER MALOSSI D.49 VESPA Primavera 3V iGet 50 ie 4T euro 4 2018-> 2020 (CA03M) ATTENTION: To be installed EXCLUSIVELY with the INJTRONIC control unit art. 5518409
3117771 CYLINDER MALOSSI D.49 VESPA Primavera 3V iGet 50 ie 4T euro 5 2021-> (CD01M) ATTENTION: To be installed EXCLUSIVELY with the INJTRONIC control unit art. 5519266B
3117771 CYLINDER MALOSSI D.49 VESPA Primavera 4V 50 4T euro 2 (C532M) For ORIGINAL HEAD
3117771 CYLINDER MALOSSI D.49 VESPA S 4V 50 4T euro 2 (C386M) For ORIGINAL HEAD
3117771 CYLINDER MALOSSI D.49 VESPA SPRINT 3V IGet 50 ie 4T euro 4 2018-> 2020 (CA01M) ATTENTION: To be installed EXCLUSIVELY with the INJTRONIC control unit art. 5518409
3117771 CYLINDER MALOSSI D.49 VESPA SPRINT 3V IGet 50 ie 4T euro 5 2021-> (CD01M) ATTENTION: To be installed EXCLUSIVELY with the INJTRONIC control unit art. 5519266B
3117771 CYLINDER MALOSSI D.49 VESPA Sprint 4V 50 4T euro 2 For ORIGINAL HEAD
